Ultra-Grit Apex XPLR AXS
Ultra-Grit Apex XPLR AXS image 2
Ultra-Grit Apex XPLR AXS image 3

Ultra-Grit Apex XPLR AXS

Built to order in the UK
The ULTRA-GRIT is Ribble’s fastest gravel bike—developed and proven by our pro gravel team, the Ribble Outliers, in the chaos of the world’s toughest off-road races, from Unbound to The Traka to The…
£2,208
V12 Finance·Klarna·PayPal
Colour
Choose Your Size
Product code: BGRAVSLRAPAXXP

Ways to pay

Why Ribble?

BUILT TO ORDER
Every Ribble is built to order by our skilled mechanics in Lancashire, UK.

LIFETIME FRAME WARRANTY
Ride hard, worry free – all our bikes have a lifetime frame and fork warranty.

30-DAY RIDE-OUT GUARANTEE
Make sure you get the perfect fit - if you're not 100% happy, return it for a full refund or swap. Terms and conditions.

30 DAYS FREE BIKE INSURANCE
Every new Ribble comes with 30 days cover included, so you’re protected from day one.

BUY DIRECT
Get more bike for your money, and have our expert team on hand if you need support.

Description

The ULTRA GRIT is Ribble’s fastest gravel bike—developed and proven by our pro gravel team, the Ribble Outliers, in the chaos of the world’s toughest off-road races, from Unbound to The Traka to The Dirty Reiver. Weighing just 9.0 kg, this race-ready machine is built for riders who embrace the unknown and charge straight into it. It pairs our lightweight, aero-optimised frameset with a rugged, fully wireless SRAM Apex XPLR AXS electronic drivetrain, durable DT Swiss G 1800 alloy wheels, versatile 45mm Schwalbe G-One R tyres, and a comfort-focused Selle Italia Model X saddle.

Groupset

Apex is the groupset designed for riders who demand versatility and performance. Apex AXS delivers a wide range 1x12 drivetrain that's ideal for gravel, bikepacking, adventure, casual rides, and everything in between. Its wireless electronic shifting ensures smooth, reliable performance with precise gear changes, excellent chain retention, and confident hydraulic disc braking. With full AXS connectivity, you can customise shift settings, monitor battery life, and update firmware—all from a single device. Intuitive and user-friendly, Apex keeps your focus where it belongs: on the ride.

Groupset

Wheelset

Boasting a wide rim profile and robust construction, the DT Swiss G 1800 Spline alloy wheelset delivers confident control and comfort across rough and unpredictable gravel terrain. Paired with 45 mm Schwalbe G-One R Performance tyres, it strikes the perfect balance of speed, grip, and stability—ideal for riders who push the boundaries across varied and demanding surfaces.

Wheelset

Handlebars

Built to take on the rough stuff, the Ribble Gravel Riser handlebars bring comfort, control, and versatility to every ride. A 20 mm rise gives you more hand positions and extra space for running a bar bag—perfect for long hauls and bikepacking missions. The flared drops widen your stance for rock-solid stability when bombing descents or picking through technical terrain. Wrapped in plush bar tape and paired with a matching RS-2 alloy stem, this setup is ready to tackle whatever the trail throws your way.

Handlebars

Saddle

Stay stable and comfortable over rough terrain—our integrated seat post clamp, combined with a proprietary D-shaped carbon seat post and the Selle Italia Model X saddle, delivers excellent rear-end compliance and effectively reduces trail chatter for all-day comfort.

Saddle

Suspension Fork Upgrade

When the gravel turns rough and the terrain gets technical, the RockShox Rudy Ultimate fork steps in to smooth out the ride. Available as an upgrade on the Ribble ULTRA-GRIT, this premium suspension fork is purpose-built for gravel racing—offering up to 30mm of travel for improved comfort, control, and confidence. Whether you're carving through gravel or hammering down technical descents, Rudy’s refined damping and lightweight design help you stay fast, focused, and in total command.

Suspension Fork Upgrade

Frame Storage

ULTRA-GRIT features a dedicated internal downtube storage compartment, built to keep your essentials such as spares, nutrition, tools accessible mid-ride without saddlebags, external clutter or aerodynamic compromise. The compartment is compatible with the Ribble RIFFT Tool Wrap, a purpose-designed wrap that organises your kit inside the frame for clean, silent, rattle-free storage. Slide it out, sort what you need, slide it back in.

Frame Storage

To assist you in selecting the correct size, simply find your height on the graphic. It illustrates our recommendations so you can be confident that the size you order will be correct. If you find that your height is between sizes, we recommend you opt for the smaller size.

For more information on why choosing the right bike size is important, please visit our Bike Sizing page, or learn more about Bike Fitting.

  • 5'3 - 5'7

    159 - 169cm

  • 5'6 - 5'9

    167 - 176cm

  • 5'9 - 5'11

    174 - 181cm

  • 5'10 - 6'1

    179 - 186cm

  • 6'0 - 6'4

    184 - 193cm

Full Spec

Please note that the exact specification below will differ based on the size and specification you select.

  • Bike

    • Apex 1 DUB Wide Crankset 165mm 40T
    • Apex AXS D1 Shift Lever & Caliper LH
    • Apex AXS D1 Shift Lever & Caliper RH
    • Apex Flattop 12spd Chain 120 Links
    • Apex XPLR AXS Rear Derailleur
    • Blanking Door Alloy
    • Carbon D-Shaped Inline Seatpost Matt Black - 280mm
    • Centre Lock Rotor Lockring
    • Centreline CL Rotor 160mm
    • Chainstay Protector
    • Compression Bushing Fits Stealth-a-Majig System AL
    • DUB BSA 68mm Road WIDE Bottom Bracket
    • Disc Caliper Bolt Black 27mm
    • Embossed Black Bar Tape
    • Frame Storage Door
    • G2 SLR SLRE Front Mech Blanking Plate
    • Integrated Seatpost Wedge
    • M3 10mm Hex 2 Countersunk P0.5 SSA2
    • M4 16mm Hex 2.5 Countersunk P0.7 Black
    • M5 12mm Hex 2.5 Grub P0.8 Black
    • M5 12mm Hex 4 Tapered Head P0.8 W/Washer Black
    • M5 16mm Hex 3 Countersunk P0.8 Black
    • MY24/25 Carbon Rubber Seat Clamp Cover
    • MY24/25 Carbon UDH Rear Thru Axle
    • Needle Insert Fits Stealth-a-Majig System SS
    • Open Hose Door Oval Plastic
    • PG1231 XPLR Cassette HG 11-44T
    • Powerpack 1 Battery & Charger (cable not included)
    • Rubber Circular Bung - 10mm Domehead 8mm Post
    • Seatpost Wedge Nut
    • Seatpost Wedge Plug
    • Storage Door Latch & Fasteners (4PCS)
    • Storage Door Latch Base
    • Storage Door O-Ring
    • Thru Axle Lever
    • Ultra-Grit Frame Blue XSM 47cm
    • Universal Derailleur Hanger
    • Warning sticker sheet Torques to be applied at PDI

  • Fork

    • Expander For Carb Steerer 1-1/8 x 65mm (Regular)
    • M5 12mm Hex 4 Tapered Head P0.8 W/Washer Black
    • MY24/25 Front Thru Axle
    • R457B Headset Bearing
    • Ultra-Grit Carbon Fork Blue

  • Wheelset

    • G-One R Performance RaceGuard TLR Tyre BLK 700x45mm
    • G1800 Disc Front Wheel 700c CL
    • G1800 Disc Rear Wheel 700c CL HG
    • Inner Tube SV17 700x28/47 Presta 40mm

  • Handlebar

    • Alloy Gravel Riser Bar Black 38cm - 47cm
    • Plastic Compression Spider 42mm ID +1.0
    • RS Spacer 10mm
    • RS Spacer 5mm
    • RS-2 Standard Cable Guide
    • RS-2 Stem Headset Bearing Cover Kit

  • Saddle

    • Selle Italia Model X Light FeC Saddle

If you're between sizes on the ULTRA-GRIT, we generally recommend choosing the smaller option. It's easier to fine-tune the fit of a smaller frame by raising the seat post or using a longer stem, whereas a larger frame leaves much less room for adjustment.

Build weights are provided for a medium‑sized frame and are intended solely as general guidance. Actual weight will vary based on the selected components and accessories, as well as standard manufacturing tolerances. These figures do not constitute a guarantee or warranty of final product weight, and we may occasionally make minor modifications to specifications without prior notice.

  • Apex XPLR AXS build: 9.0 kg (carbon forks) / 9.7 kg (RockShox Rudy Ultimate)
  • Rival XPLR AXS build: 8.9 kg (carbon forks) / 9.6 kg (RockShox Rudy Ultimate)
  • Force XPLR AXS build: 8.3 kg (carbon forks) / 9.0 kg (RockShox Rudy Ultimate)
  • Red XPLR AXS build: 8.0 kg (carbon forks) / 8.7 kg (RockShox Rudy Ultimate)
  • Outliers Edition build: 8.0 kg (carbon forks) / 8.7 kg (RockShox Rudy Ultimate)
  • SPORTFIT build: 8.9 kg (carbon forks) / 9.6 kg (RockShox Rudy Ultimate)
  • Frame only (medium): 890 g (raw finish)

Like all Ribble bikes, the ULTRA-GRIT is covered by a lifetime warranty on frame and forks for the original purchaser. This includes any manufacturing defects in materials or workmanship. The standard manufacturer's warranty applies to all other components including 3rd party suspension forks.

Yes, the ULTRA-GRIT frameset is UCI-approved and has been raced extensively by our pro gravel team, the Outliers.

Yes. The ULTRA-GRIT is available with the optional RockShox Rudy suspension fork. This upgrade improves comfort and control on rougher gravel trails, helping you stay fast and confident when the terrain gets technical.

Yes. The ULTRA-GRIT features enhanced cable integration for a clean, cable-free look. Cables are hidden from view, protected from the elements and shielded from drag.

The ULTRA-GRIT comes equipped with fast, grippy and versatile 45 mm gravel tyres, with frame clearance for tyres up to 50 mm wide. When mudguards are fitted, maximum clearance is reduced to around 45 mm, depending on tyre brand and tread. The fork can also accept a 29 x 2.1" (700 x 53c) mountain bike tyre.

Yes. The ULTRA-GRIT can be fitted with a rear pannier rack using our adaptor kit, providing a practical way to carry up to 15 kg of extra gear (kit sold separately).

Yes. A removable mudguard bridge makes fitting mudguards easy (kit sold separately). We also offer a combined mudguard and rack-mount kit for anyone looking to fit both.

The ULTRA-GRIT is compatible with a 68 mm BSA threaded bottom bracket. BSA threaded bottom brackets offer advantages over press-fit designs, particularly in terms of ease of installation, maintenance and reduced creaking. The threaded design provides a more robust connection, and the standardised threads make it simpler to install and remove.

The ULTRA-GRIT features a 1.5" integrated headset and R457B 52 x 42 x 7 mm 45° x 45° headset bearings top and bottom.

The ULTRA-GRIT features a D-shaped carbon seatpost with an integrated wedge clamp, designed for compatibility with carbon-railed saddles. XS–SM frames are equipped with a 280 mm post, while M–XL frames come with a 330 mm post.

The ULTRA-GRIT features two bottle cage mounts with one on the seat tube and one on the downtube. Both are positioned to work seamlessly with Ribble Aero Bottle Cages for optimal aerodynamic performance.

The ULTRA-GRIT includes extra luggage mounts on the top tube and underneath the downtube.

Thru Axles:

Yes. While the ULTRA-GRIT comes with a 1x drivetrain, it can also accommodate a braze-on front derailleur using an optional derailleur hanger (sold separately) and 2x gravel chainsets (31T/48T max).

The ULTRA-GRIT uses a universal derailleur hanger (UDH), standardising hanger design across bikes. That means no more hunting for a frame-specific hanger with just one simple, universal solution.

The ULTRA-GRIT has a maximum recommended system weight of 120 kg, including bike, rider and luggage.

No. Pedals aren’t included as riders use different systems. You can, however, choose from a range of best-selling pedals when configuring your bike.
